Video Transmission

• Video Transmission System

• O3+

• Max Transmission Distance (unobstructed, free of interference)

• 15 km (FCC); 8 km (CE/SRRC/MIC)

• Operating Frequency [1]

• 2.400-2.4835 GHz5.725-5.850 GHz

• Antennas

• 4 Antennas, 2T4R

• Transmitter Power (EIRP)

• 2.4 GHz: ≤33 dBm (FCC); ≤20 dBm (CE/SRRC/MIC)

• 5.8 GHz: ≤33 dBm (FCC); ≤14 dBm (CE); ≤23 dBm (SRRC)

Wi-Fi

• Protocol

• 802.11a/b/g/n/ac/ax Support 2×2 MIMO Wi-Fi

• Operating Frequency [1]

• 2.400GHz-2.4835 GHz; 5.725-5.850 GHz

• Transmitter Power (EIRP)

• 2.4 GHz: ≤26 dBm (FCC); ≤20 dBm (CE/SRRC/MIC)5.8 GHz: ≤26 dBm (FCC/SRRC); ≤14 dBm (CE)

Bluetooth

• Protocol

• Bluetooth 5.1

• Operating Frequency

• 2.400-2.4835 GHz

• Transmitter Power (EIRP)

• ≤8 dbm

Screen

• Resolution

• 1920×1080

• Dimensions

• 5.5 inches

• Frame Rate

• 60 fps

• Brightness

• 1000 nits

• Touch Control

• 10-point multi-touch

General Specs

• Battery

• Li-ion (5000 mAh @ 7.2 V)

• Charging Type

• Recommended to be charged with USB charger at 12 V or 15 V

• Rated Power

• 12 W

• Storage Capacity

• 32GB internal + expandable storage via microSD card

• Charging Time

• 2 hours (with USB charger at 12 V), 1.5 hours (with USB charger at 15 V)

• Operating Time

• 3 hours

• Video Output Port

• Mini-HDMI port

• Operating Temperature

• -10° to 40°C (14° to 104° F)

• Storage Temperature Range

• Less than one month: -30° to 60° C (-22° to 140° F) One to three months: -30° to 45° C (-22° to 113° F) Three to six months: -30° to 35° C (-22° to 95° F) More than six months: -30° to 25° C (-22° to 77° F)

• Charging Temperature

• 5° to 40° C (41° to 104° F)

• Supported Aircraft Models [2]

• DJI Mavic 3, DJI Mavic 3 Cine, DJI Air 2S

• GNSS

• GPS + Galileo + GLONASS

• Dimensions

• 183.27×137.41×47.6 mm (antennas folded, controllers not mounted)183.27×203.35×59.84 mm (antennas unfolded, controllers mounted)

• Weight

• Approx. 680 g

• Model

• RM510
